The ARC - Angled Rescue Cylinder - Master STL Bundle (Complete System)

The Universal Digital Solution for Angulated Implants.

Unlock the full potential of the Angle Rescue Cylinder. This Master Bundle gives you the complete digital warehouse to correct implant trajectories by up to 15 degrees.

The Problem: Screw access coming out of the facial? Don't have the right temp cylinder in stock? The Solution: Print your own 15° angled correction in-house for pennies.

What is included ($200):

1. The Master STL Files (Universal Compatibility)

• Milling Set (1:1): 0°, 5°, 10°, 15° (Precision geometry for milling).
• Printing Set (0.05mm Offset): 0°, 5°, 10°, 15° (Optimized for resin shrinkage).
• Printing Set (0.15mm Offset): 0°, 5°, 10°, 15° (Optimized for resin shrinkage).

2. The Implementation Guide

• SOP Video Access: Screen recording showing exactly how to nest and print these files for success. Coming Soon
• Parts List PDF: Direct links to the compatible DESS screws and drivers needed for final assembly.

Technical Details:

• Format: Open Binary STL
• Correction: Up to 15 degrees of trajectory shift.

Disclaimer & Usage:

• Laboratory Use Only: These files are sold as CAD assets for laboratory, educational, and custom manufacturing purposes.
• Non-Medical Device: These files are not FDA-cleared medical devices. The clinician/laboratory assumes full responsibility for manufacturing validation and material selection.
• Compatibility: Designed for use with compatible DESS® components. We are not affiliated with DESS®.
